Specification	SkyEye62AC Plus	SkyEye62AM Plus	SkyEye45AC Plus	SkyEye24AC Plus	SkyEye26AC Plus	SkyEye26AM Plus
Sensor Type	Color CMOS	Monochrome CMOS	Color CMOS	Color CMOS	Color CMOS	Monochrome CMOS
Sensor	IMX455	IMX455	IMX366	IMX410	IMX571	IMX571
Megapixels	61 MP	61 MP	44.72 MP	24 MP	26 MP	26 MP
Resolution	9568×6380	9568×6380	8192×5460	6064×4040	6224×4168	6224×4168
Pixel size	3.76μm	3.76μm	4.40μm	5.94μm	3.76μm	3.76μm
ADC	16bit	16bit	14bit	14bit	16bit	16bit
Quantum Efficiency	>80%	>91%	>80%	>80%	>80%	>91%
Full Well Capacity	51ke⁻ (107ke⁻in LCG)	51ke⁻ (111ke⁻in LCG)	73ke⁻ (14.9ke⁻in HCG)	104ke⁻ (20ke⁻in HCG)	51ke⁻	51ke⁻
Read Noise	2.58–0.89e⁻ (LCG)	2.8–0.97e⁻ (LCG)	6.03–3.57e⁻ (LCG)	4.48–1.95e⁻ (LCG)	2.6–1.14e⁻ (LCG)	2.27–1.41e⁻ (LCG)
Low-noise Read Noise	1.72–0.89e⁻ (HCG)	1.95–0.9e⁻ (HCG)	1.35–0.88e⁻ (HCG)	0.68–0.3e⁻ (HCG)	1.18–0.79e⁻ (HCG)	1.16–0.77e⁻ (HCG)
Dynamic Range	85.8 dB	88.3 dB	81.66 dB	87.3 dB	86.8 dB	87.9 dB
Cooling Delta	-35°C / -40°C	-35°C / -40°C	-35°C / -40°C	-35°C / -40°C	-35°C / -43°C	-35°C / -43°C
Protective Window	IR-cut / AR-coated	AR-coated	IR-cut / AR-coated	IR-cut / AR-coated	IR-cut / AR-coated	AR-coated
Spectral Range	380–690nm	380–1100nm	380–690nm	380–690nm	380–690nm	380–1100nm
Back Focus	17.5/12.5mm	17.5/12.5mm	17.5/12.5mm	17.5/12.5mm	17.5/12.5mm	17.5/12.5mm

SkyEye Plus Series

SkyEye Plus DSO Cooled Cameras
